100% Sourced in Australia
PROUDLY AUSTRALIAN MADE
LOCK UP KIT
Frame - 1 Delivery
- Prefabricated Trusses
- Prefabricated Wall Frames
- Bracing And Tie Downs for Frames and Trusses
- Metal Roof Battens to Main & Verandah Roofs
- Fibre-Cement Lined Eaves & Verandah incl. Steel battens (if required)
- Verandah Beams, Posts, Rafters & Brackets/Connections
- 90 x 90 SHS Verandah Posts (terminate at deck height)
- Site Installation Manual if required
- Design & Certification for structure
Insulation - 1 Delivery (with Cladding)
- Very High Permeable Wall Wrap For All External Walls
- R1.8 Roof Insulation 75mm blanket for Main House Area (Not on skillion verandah's unless there is no change of pitch to main roof) – subject to BASIX / Energy Report
Cladding - 1 Delivery (with Insulation)
- BGC Duraplank FC weatherboards 4200 x 230 Smooth (or Hardiplank equivalent), Joiners, Foot-mould & Corners (fixings by builder)
- 4.5mm Fibre Cement Eaves & Verandah Sheets (BGC Durasheet)
- LOSP 31 x 18 H2 DAR for Eaves/Cladding Junction
Roofing - 1 Delivery
- All Colourbond Roofing, Guttering, Fascia, Barge Capping, Fixings & PVC Downpipes ,Elbows
- Fibre Cement Eaves and Verandah lining
- Metal battens
Windows and Doors - 1 Delivery
- Single Glazed Powder Coated Aluminium Windows & Sliding Doors including Nylon Mesh Screens and Locks (Foldable head flashings can be supplied if requested) – Single Glazing subject to BASIX / Energy Report
- Solid External Door, Jambs And Stainless Steel Entrance Lock
- (Head flashing by others)
LINING KIT
Plasterboard & Accessories - 1 Delivery
- 10mm Plasterboard - For 2.4m Walls & Ceilings
- Plasterboard accessories incl. adhesives, base-coat, top-coat, fixings etc.
- Ceminseal Wallboard RE 6MM or Aquacheck for wet areas in Bathroom, Laundry, Ensuite
- 50-90mm Cove Cornice's
- Metal Top Hat Ceiling Battens & Fixings (if required)
Second Fix - 1 Delivery
- 66 x 18mm 5.4m Pine Dar Fj Primed splayed edge Skirting and Architraves
- Hume Primecoat Prehung Internal Doors
- 112 x 18mm FJ Primed Pine Door Jamb Set, Wall mounted doorstops.
- Lane Security Brushed Satin Chrome Victoria Privacy Leverset (Bathroom & WC)
- Lane Victoria Brushed Satin Chrome Entry Leverset (BR's, WIR & Laundry)
- Zenith 70mm Polished Stainless Steel Fixed Pin Butt Hinge Satin Chrome Doorstops
Robes (supplied as per floor plan for designs with an enclosed area of greater than 60 sqm - Delivery with Second Fix)
- Hume Smart Robe Primecoat Wardrobe Door with wheels fitted to bottom of door & Hardware
- Hume Smartrobe Sliding track and Jamb
- 110 x 18mm 2.7m Primed Pine DAR frame
- 16mm White Melamine Shelving
- 42 x 18mm Finger Jointed DAR Primed Pine Shelf Supports
- White Iron-On Melamine Edging
- White buttons to cover screw heads
- 19mm Chrome Tube Rod, Pillar Centre and Ends
Insulation (If Required - Delivery with Second Fix)
- R2.0 External Wall Insulation – subject to BASIX / Energy Report
- R1.8 Ceiling Insulation, if stipulated in BASIX / Energy Report
- Note: Our insulation make-up is generally suited to warmer climates so depending on your climate zone, orientation, amount of glass etc. upgrades may be required
FINAL KIT
2 Deliveries (1 for Front of wall items, 1 for Kitchen joinery)
Note this is fully customizable with customer to confirm all selections.
- 450mm White Vanity Unit + Basin, Flick mixers
- White 910 mm X 900 mm Shower Base, Chrome Tap Set & Shower Arm
- Ceramic WC Pan, Cistern
- S/Steel 1-3/4 Bowl Kitchen Sink & Kitchen Sink Mixer
- Chrome Toilet Roll Holder
- Chrome Double Towel Rail 760 mm
- Stainless Steel 45 Litre Laundry Cabinet & Bowl, Chrome Tap Set Chrome & Laundry Arm
- Chrome Washing Machine Tap set
- Stainless Steel Electric Multi Function U/Bench Oven 60cm (or Gas equivalent)
- Stainless Steel Cooktop Solid Electric (or Gas equivalent)
- Rangehood (Only supplied if overhead cupboards shown on plan)
- Kitchen Cabinets (overhead cabinets supplied as per floor plan for designs with an enclosed area of greater than 60 sqm)
- Doors (MDF with thermal vinyl coating) including 1 set 4 drawers, Cut to Measure Benchtop 38mm.
- Thick Compact Radius, Soft Close Hardware 96mm Round Bar Handles, Hinges, Runners, Handles, Legs, Panels And Kickboards, Cutlery cabinet etc.
OPTIONAL FLOOR KIT INCLUSIONS
Floor - 1 Delivery
- Light gauge steel bearer & joist system designed and certified by fabricator
- 19mm Yellow-tongue Sheeting
- Floor Adhesive
- Merbau Hardwood Decking 90X19
- NOTE: SUB FLOOR POSTS NOT INCLUDED, BUT CAN BE SUPPLIED AT EXTRA COST IF REQUIRED (REQUIRES FOOTING DESIGN).
GENERAL
- iBuild standard floor plan, elevation plan and section plan, as well as a complimentary site plan if client provides acceptable land survey and other information pertinent to location and orientation.
- Energy report assessment under the Deemed to Satisfy Provisions of Building Code of Australia or Performance Provisions (extra $300)
EXCLUSIONS & OPTIONAL
Lock up kit Exclusions
- Raked ceiling (unless specified on plans)
- All bolts, chemical fixings etc. if required (builder to supply)
- Any engineered Structural Steel other than Verandah Beam & Posts
- Nails/screws/bolts/angles/packers and any other fixings or associated sundry unless noted above
- Wall frame tie downs (to be determined by engineering/builders preferred specification)
- Verandah post stirrups (subject to builders preferred specification)
- Verandah Ballustrades
- External or Internal Stairs, Landings & Handrails
- FC sheet to wet areas (builder to advise if waterproofing yellow-tongue or prefer to change substrate for floor finishes)
- Sealant / gap filler for weatherboards
- Window flashings (foldable aluminium head flashing can be supplied if requested)
- External Window architraves
- Electrical layouts, wiring, fittings & underground power
Lining kit Exclusions
- Paint or floor coverings
- All fixing nails or adhesives
- External or Internal Stairs, Landings & Handrails
- Wet area floor sealants, waterproofing etc.
- Tiles or shower screens
- Sealant / gap filler for weatherboards
FINAL kit Exclusions
- Plumbing or electrical supplies
- Mirrors
- Packers
- Floor finishes
- Tiles or shower screens
fLOOR kit Exclusions
- Sub-floor posts - can be supplied at extra cost if required, requires footing design
- Footing engineering design (optionally arranged)
- Floor insulation - can be supplied extra if stipulated in Energy Report
- Cladding to sub-floor
- Fixings for Cladding or floor boards or Framing except where noted
- Footing materials
- Ant caps / termite treatment other than H2/3 and LOSP impregnated timber (no allowance for T2 timber unless noted otherwise)
- Footing materials
- FC sheet to wet areas (builder to advise if waterproofing yellow-tongue or prefer to change substrate for floor finishes)
General Exclusions
- Any form of onsite labour (each kit)
- Land survey
- Soil tests
- BAL, wind rating and other planning related reports
- Landscape designs or plans
- Any other requirements for individual council
- Hot water sytems, heating, cooling systems
- Light fittings, exhaust fans, smoke detectors
CLICK ON THE IMAGE BELOW TO DOWNLOAD IBUILD INCLUSIONS BOOKLET
One on One with iBuild Client Alison
Aussie Manufactured Excellence
Kit Home Prices Table Walkthrough
Quality Assurance From Reputable Suppliers
You May Also Be Interested In
The Designer Series of granny flats and kit homes are a modern revamp of our standard line. With new livable design standards in play along with ever-increasing energy efficiency requirements, we’ve included some standard upgrades in our Designer Series inclusions.
Key inclusions within our Designer Series price include:
- 2.7m high ceilings and taller 2340mm doors to match
- Double-glazing windows and sliding doors
- James Hardie Axon Cladding
- R2.5 wall insulation
- R6.0 ceiling insulation
Scroll down for the full list of inclusions and exclusions for our Designer Series.
100% Sourced in Australia
PROUDLY AUSTRALIAN MADE
LOCK UP KIT
Frame - 1 Delivery
- Prefabricated Trusses
- Prefabricated Wall Frames
- Bracing And Tie Downs for Frames and Trusses
- Metal Roof Battens to Main & Verandah Roofs
- Fibre-Cement Lined Eaves & Verandah incl. Steel battens (if required)
- Verandah Beams, Posts, Rafters & Brackets/Connections
- 90 x 90 SHS Verandah Posts (terminate at deck height)
- Site Installation Manual if required
- Design & Certification for structure
Insulation - 1 Delivery (with Cladding)
- Very High Permeable Wall Wrap For All External Walls
- R1.8 Roof Insulation 75mm blanket for Main House Area (Not on skillion verandah's unless there is no change of pitch to main roof) – subject to BASIX / Energy Report
Cladding - 1 Delivery (with Insulation)
- James Hardie Smooth Axon cladding (or equivalent), Joiners, Foot-mould & Corners (fixings by builder)
- 4.5mm Fibre Cement Eaves & Verandah Sheets (BGC Durasheet)
- LOSP 31 x 18 H2 DAR for Eaves/Cladding Junction
Roofing - 1 Delivery
- All Colourbond Roofing, Guttering, Fascia, Barge Capping, Fixings & PVC Downpipes ,Elbows
- Fibre Cement Eaves and Verandah lining
- Metal battens
Windows and Doors - 1 Delivery
- Double Glazed Powder Coated Aluminium Windows & Sliding Doors including Nylon Mesh Screens and Locks (Foldable head flashings can be supplied if requested)
- Solid External Door, Jambs And Stainless Steel Entrance Lock
LINING KIT
Plasterboard & Accessories - 1 Delivery
- 10mm Plasterboard - For 2.7m Walls & Ceilings
- Plasterboard accessories incl. adhesives, base-coat, top-coat, fixings etc.
- Ceminseal Wallboard RE 6MM or Aquacheck for wet areas in Bathroom, Laundry, Ensuite
- 50-90mm Cove Cornice's
- Metal Top Hat Ceiling Battens & Fixings (if required)
Second Fix - 1 Delivery
- 66 x 18mm 5.4m Pine Dar Fj Primed splayed edge Skirting and Architraves
- Hume Primecoat Prehung Internal Doors
- 112 x 18mm FJ Primed Pine Door Jamb Set, Wall mounted doorstops.
- Lane Security Brushed Satin Chrome Victoria Privacy or Entry Leversets
- Zenith 70mm Polished Stainless Steel Fixed Pin Butt Hinge Satin Chrome Doorstops
Robes (supplied as per floor plan for designs with an enclosed area of greater than 60 sqm - Delivery with Second Fix)
- Hume Smart Robe Primecoat Wardrobe Door with wheels fitted to bottom of door & Hardware
- Hume Smartrobe Sliding track and Jamb
- 110 x 18mm 2.7m Primed Pine DAR frame
- 16mm White Melamine Shelving
- 42 x 18mm Finger Jointed DAR Primed Pine Shelf Supports
- White Iron-On Melamine Edging
- White buttons to cover screw heads
- 19mm Chrome Tube Rod, Pillar Centre and Ends
Insulation (If Required - Delivery with Second Fix)
- R2.5 External Wall Insulation – subject to BASIX / Energy Report
- R6.0 Ceiling Insulation - subject to BASIX / Energy Report
- Designer series insulation is higher grade than our standard inclusion, though depending on your climate zone, orientation, amount of glass etc. upgrades may be required to reach minimum energy requirements
FINAL KIT
2 Deliveries (1 for Front of wall items, 1 for Kitchen joinery)
Note this is fully customizable with customer to confirm all selections.
- 450mm White Vanity Unit + Basin, Flick mixers
- White 910 mm X 900 mm Shower Base, Chrome Tap Set & Shower Arm
- Ceramic WC Pan, Cistern
- S/Steel 1-3/4 Bowl Kitchen Sink & Kitchen Sink Mixer
- Chrome Toilet Roll Holder
- Chrome Double Towel Rail 760 mm
- Stainless Steel 45 Litre Laundry Cabinet & Bowl, Chrome Tap Set Chrome & Laundry Arm
- Chrome Washing Machine Tap set
- Stainless Steel Electric Multi Function U/Bench Oven 60cm
- Stainless Steel Cooktop Solid Electric
- Rangehood (Only supplied if overhead cupboards shown on plan)
- Kitchen Cabinets (overhead cabinets supplied as per floor plan for designs with an enclosed area of greater than 60 sqm)
- Doors (MDF with thermal vinyl coating) including 1 set 4 drawers, Cut to Measure Benchtop 38mm
- Thick Compact Radius, Soft Close Hardware 96mm Round Bar Handles, Hinges, Runners, Handles, Legs, Panels And Kickboards, Cutlery cabinet etc.
OPTIONAL FLOOR KIT INCLUSIONS
Floor - 1 Delivery
- Light gauge steel bearer & joist system designed and certified by fabricator
- 19mm Yellow-tongue Sheeting
- Floor Adhesive
- Merbau Hardwood Decking 90X19
General
- iBuild standard floor plan, elevation plan and section plan, as well as a complimentary site plan if client provides acceptable land survey and other information pertinent to location and orientation.
- Energy report assessment under the Deemed to Satisfy Provisions of Building Code of Australia or Performance Provisions (extra $300)
EXCLUSIONS & OPTIONAL
Lock up kit Exclusions
- Raked ceiling (unless specified on plans)
- All bolts, chemical fixings etc. if required (builder to supply)
- Any engineered Structural Steel other than Verandah Beam & Posts
- Nails/screws/bolts/angles/packers and any other fixings or associated sundry unless noted above
- Wall frame tie downs (to be determined by engineering/builders preferred specification)
- Verandah post stirrups (subject to builders preferred specification)
- Verandah Ballustrades
- External or Internal Stairs, Landings & Handrails
- FC sheet to wet areas (builder to advise if waterproofing yellow-tongue or prefer to change substrate for floor finishes)
- Sealant / gap filler for weatherboards
- Window flashings (foldable aluminium head flashing can be supplied if requested)
- External Window architraves
- Electrical layouts, wiring, fittings & underground power
Lining kit Exclusions
- Paint or floor coverings
- All fixing nails or adhesives
- External or Internal Stairs, Landings & Handrails
- Wet area floor sealants, waterproofing etc.
- Tiles or shower screens
- Sealant / gap filler for weatherboards
FINAL kit Exclusions
- Plumbing or electrical supplies
- Mirrors
- Packers
- Floor finishes
- Tiles or shower screens
fLOOR kit Exclusions
- Sub-floor posts - can be supplied at extra cost if required, requires footing design
- Footing engineering design (optionally arranged)
- Floor insulation - can be supplied extra if stipulated in Energy Report
- Cladding to sub-floor
- Fixings for Cladding or floor boards or Framing except where noted
- Footing materials
- Ant caps / termite treatment other than H2/3 and LOSP impregnated timber (no allowance for T2 timber unless noted otherwise)
- Footing materials
- FC sheet to wet areas (builder to advise if waterproofing yellow-tongue or prefer to change substrate for floor finishes)
General Exclusions
- Any form of onsite labour (each kit)
- Land survey
- Soil tests
- BAL, wind rating and other planning related reports
- Landscape designs or plans
- Any other requirements for individual council
- Hot water sytems, heating, cooling systems
- Light fittings, exhaust fans, smoke detectors
CLICK ON THE IMAGE BELOW TO DOWNLOAD IBUILD INCLUSIONS BOOKLET
One on One with iBuild Client Alison
Aussie Manufactured Excellence
Kit Home Prices Table Walkthrough
Quality Assurance From Reputable Suppliers
You May Also Be Interested In
Comparing the Classic Range and Designer Series Inclusions
| Category | Classic Range | Designer Series |
|---|---|---|
| Ceiling Height | 2.4m high ceilings | 2.7m high ceilings |
| Doors | Standard height doors | Taller 2340mm doors |
| Windows | Single-glazed powder-coated aluminum windows | Double-glazed powder-coated aluminum windows |
| Sliding Doors | Single-glazed powder-coated aluminum sliding doors | Double-glazed powder-coated aluminum sliding doors |
| Cladding | BGC Duraplank FC weatherboards or Hardiplank equivalent | James Hardie Axon Cladding |
| Wall Insulation | R1.8 insulation | R2.5 insulation |
| Ceiling Insulation | R1.8 roof insulation (75mm blanket) | R6.0 ceiling insulation |
| Verandah Posts | 90 x 90 SHS Verandah posts, terminate at deck height | 90 x 90 SHS Verandah posts, terminate at deck height |
| Roofing | Colorbond roofing, gutters, fascias, barge capping, PVC downpipes | Colorbond roofing, gutters, fascias, barge capping, PVC downpipes |
| Installation Manual | Provided if required | Provided if required |
| External Doors | Solid external door with stainless steel entrance lock | Solid external door with stainless steel entrance lock |
| Wall Wrap | Very high permeable wall wrap for all external walls | Very high permeable wall wrap for all external walls |
| Verandah & Eaves | Fibre-cement lined eaves and verandah sheets | Fibre-cement lined eaves and verandah sheets |
| Frame & Trusses | Prefabricated trusses and wall frames | Prefabricated trusses and wall frames |
| Internal Doors | Hume Primecoat Prehung internal doors | Hume Primecoat Prehung internal doors |
| Skirting and Architraves | 66 x 18mm Primed MDF | 66 x 18mm Primed MDF |
| Bathroom & Laundry | Ceminseal wallboard for wet areas | Ceminseal wallboard for wet areas |
| Kitchen | Customisable with 38mm benchtop, 4 drawers, MDF doors | Customisable with 38mm benchtop, 4 drawers, MDF doors |
| Appliances | Stainless steel electric oven, cooktop, rangehood | Stainless steel electric oven, cooktop, rangehood |
| Optional Floor Kit | Light gauge steel bearer & joist system, Merbau hardwood decking | Light gauge steel bearer & joist system, Merbau hardwood decking |
| Energy Efficiency Upgrades | Material upgrade may be required as per BASIX/Energy Reports | Higher-grade insulation (R2.5 walls, R6.0 ceilings) and double-glazed windows |
| Source of Materials | 100% sourced in Australia | 100% sourced in Australia |
